Bộ quản lý 4 camera ANPR
Lượt xem: 188 - Ngày đăng: 28/07/2023
- Hỗ trợ kết nối với camera đạn ANPR và trình quản lý ra vào tất cả trong một.
- Với hiệu suất cao, nền tảng nhúng đảm bảo hoạt động ổn định trong thời gian dài.
- Nhiều giao diện mạng có thể truy cập vào một số lượng lớn camera và tiết kiệm chi phí chuyển mạch
- Được thiết kế cho các lĩnh vực công nghiệp, thiết bị có khả năng thích ứng cao và có thể được sử dụng trong môi trường từ -30 °C đến 70 °C (-22 °F đến 158 °F)
- Chắc chắn, nhỏ gọn, không có quạt và kích thước nhỏ,cabin gắn trên cột
- Hỗ trợ báo động âm thanh và tải lên báo động sau khi mở cửa tủ.
- Hỗ trợ hoạt động web và SDK.
- Tất cả các giao diện được thiết kế trên một mặt giúp dễ dàng thi công và vận hành.
Nội dung
Network | |
---|---|
Data Uploading | Supports ANR (Automatic Network Replenishment) and manual re-upload of traffic data. |
Storage | |
Number Of HDD | 1 × 3.5" SATA hard disk and 1 × 2 TB hard disk. Up to 8 TB hard disk is supported. |
Parking Data Storage And Uploading | Supports roadside parking vehicles information (videos and pictures) storage. Supports uploading data via EHome, SDK, and HTTP. |
Video Recording | Supports video storage. The set stream and hard disk capacity determine the video retention duration. |
Terminal | |
Operating System | Embedded Linux operation system |
Local Operation | Web |
Interface | |
Indicator | Power indicator, alarm indicator, hard disk indicator, working indicator |
Alarm Input | 1 |
Alarm Output | 1 |
RS-232 | 2 |
RS-485 | 1 |
USB | 1 × USB 2.0 interface |
Network Interface | 4 × 100M Ethernet interfaces, 2 × 10M/100M/1000M self-adaptive Ethernet interfaces, and 2 × gigabit SFP optical fiber interfaces 8 × 100M and 1 gigabit optical port compose the internal network, and the other 1 gigabit combo port is for the external network. The network segment of the internal network can be different from that of the external network. Supports accessing camera across network segments, which saves the system IP address resources. |
General | |
Working Temperature & Humidity | -30 °C to 70 °C (-22 °F to 158 °F) 10% to 90% |
Power Supply | 12 VDC/5 A adapter |
Working Consumption | 20 W |
Dimensions | 245 mm × 175 mm × 60 mm (9.65" × 6.89" × 2.36") |
Weight | 2.0 kg (4.4 lb.) (with 1 hard disk) |
